Product Overview
The Baudouin 12M33 PowerKit Gas Engine is a 12‑cylinder V‑type gas engine engineered for high‑capacity generator applications across industrial, commercial, and utility segments. Designed with lean‑burn technology and advanced electronic control, it delivers reliable continuous and prime power performance with low NOx emissions and excellent transient response. This engine is ideal for natural gas, biogas, landfill gas, and low‑energy fuel applications.
Key Features
- Cylinders: 12 (V‑type)
- Bore & Stroke: 150 x 185 mm
- Total Displacement: 39.2 liters
- Fuel System: Open chamber / lean burn gas
- Governor: ECU electronic governor
- Aspiration: Turbocharged and air‑to‑water aftercooled
- Low Emissions: Designed for reduced NOx in gas operation
Technical Specifications
| Power Output (COP / PRP) | 50 Hz: – 12M33G10N0/5: 765 kWm COP, 680 kWe COP, 800 kWe PRP @ 1500 RPM 60 Hz: – 12M33G14N0/6: 816 kWm COP, 720 kWe COP, 850 kWe PRP @ 1800 RPM |
|---|---|
| Engine Type | 12‑cylinder V, 4‑stroke gas engine |
| Bore & Stroke | 150 x 185 mm |
| Total Displacement | 39.2 liters |
| Engine Rotation | Counterclockwise |
| Rated Speed | 1500 RPM (50 Hz) / 1800 RPM (60 Hz) |
| Fuel System | Open chamber, lean burn gas |
| Aspiration | Turbocharged & air‑to‑water aftercooled |
| Emissions | Low NOx lean‑burn gas design (varies by fuel type and configuration) |
| Dimensions (L x W x H) | Approximately 2164 x 1497 x 1710 mm (PowerKit configuration) |
| Dry Weight | Approximately 3,390 kg (engine only) |
Applications
The Baudouin 12M33 PowerKit Gas Engine is well suited for:
- Natural gas and biogas generator sets
- Landfill and waste‑to‑energy power units
- Continuous and prime power plants
- Industrial and utility standby systems
Certifications & Standards
- Designed for full duty cycle capability — standby to continuous power
- Lean‑burn technology for low NOx emissions in gas operation
