Product Overview
The Baudouin 6 M33.2 is a powerful 6-cylinder inline diesel generator set designed for marine auxiliary power applications. It delivers reliable power outputs up to 770 kVA at 50 Hz and 880 kVA at 60 Hz, ensuring consistent and efficient performance in demanding maritime environments. Featuring a robust design with advanced common rail injection technology, it offers excellent fuel efficiency and extended maintenance intervals for cost-effective operation.
Key Features
- High Power Output: Provides continuous reliable power within its performance category.
- Advanced Injection System: Common Rail electronic fuel injection enhances fuel efficiency and engine responsiveness.
- Easy Maintenance: Designed with accessible components and unit cylinder heads for simplified servicing.
- Cost Efficiency: Extended Mean Time Between Overhauls (MTBO) reduces operating costs.
Technical Specifications
| Power Output (PRP) | 50 Hz: 770 kVA / 616 kWe @ 1500 RPM 60 Hz: 880 kVA / 704 kWe @ 1800 RPM |
|---|---|
| Engine Type | 6-cylinder inline, 4-stroke diesel |
| Bore & Stroke | 170 x 210 mm |
| Total Displacement | 22.7 liters |
| Compression Ratio | 14.5:1 |
| Engine Rotation | Counterclockwise (ISO 1204 standard) |
| Idle Speed | 650 RPM |
| Fuel Consumption | 50 Hz: Approx. 155 l/h @ 100% load 60 Hz: Approx. 175 l/h @ 100% load |
| Emissions | IMO II / EPA III compliant |
| Dimensions (L x W x H) | 2635 x 1225 x 1555 mm |
| Dry Weight | Approximately 3200 kg |
Applications
The 6 M33.2 generator set is ideal for marine auxiliary power on:
- Commercial vessels
- Fishing vessels
- Passenger ships
- Offshore support vessels
Certifications & Standards
- Compliant with ISO 3046/1 standards
- Designed for harsh marine environments
- IMO II / EPA III emissions compliant
